C4D1216 C4D1218 Asymmetrical light SS316 LED Underwater Swimming Pool Lights

C4D1216 C4D1218 Asymmetrical light SS316 LED Underwater Swimming Pool Lights

Model No.︰C4D1216 C4D1218

Brand Name︰Comlite

Country of Origin︰China

Unit Price︰-

Minimum Order︰-

Inquire Now

Product Description

C4D1216 C4D1218 Asymmetrical light SS316 LED Underwater Swimming Pool Lights, Asymmetrical Underwater Pool Lights Stainless Steel , LED Pool Lamp Corrosion Resistant

Description

Working Voltage: DC24V LED Brand And Quantity: 12pcs 2W Osram/ CREE/ CITIZEN LED Or 3-in-1 RGB LED
LED Emitting Color: Single Color Or RGB Full Color Typ. Power(W): 22.3W Or 27.6W
Typ. Luminance(lm): Cool White=950, Warm White=807 Housing Material: Completely Stainless Steel SUS 316# Housing
Optics Lens: Asymmetrical Optics Lens, 45°|35°, Efficiency≥85% CRI: 80+
IP Rating And IK Class: IP68 And IK08 Mounting Sleeve: PVC Mounting Sleeve
Front Cover: Diameter Φ185mm, Stainless Steel SUS 316#
High Light:

underwater swimming pool lights

led underwater pond lights



C4D1216, C4D1218(RGB 3-in-1 Full Color) 12 * 2W Dia. Φ185 CRI 80 + Underwater LED Pool Lamp with Asymmetrical Light

Completely stainless steel SUS 316# housing & Front Plate and PVC mounting Sleeve





Features and Benefits:

1. Big diameter size Φ185 and thin body 65mm(included the height of cable gland) ;

2. Made of molding 316 Stainless Steel resistant to corrosion

3. Light source is used world well-known LED brands, such as: Osram, Cree, Citizen, Epistar and etc.,

4. Dimming options include 0-10 V , PWM protocols, DALI and DMX+DMX deocder;

5. RGB type color changing works with DMX+DMX deocder;

6. Exert force area of ø10 = 210kgs ø30= 550gs ø60 =800kgs capacity loading; IK08 level;

7. Use the Silcone with good stickiness and thermal effect for reach the purpose of radiating and prevent moisture;
8. Built-in Radiator helps prolong lifespan of LEDs;

9. IP68 rating waterproof outdoor use designed and can be submersed into water less than 1meter indepth;

10. Asymmetrical optics lens, 45°|35°, efficiency≥85%.







Applications:

LED Underwater light is the perfect solution for decorative illumination water landscapes and illumination. With an IP68 waterproof grade, it is perfect for Swimming pool, ponds, fountain, aquariums, recreational facilities, decoration underwater, park lake, water stage and other outdoor place for atmosphere decoration.



Warning:
This high-power LED housing is all stainless steel, must be installed underwater
staying cold to prevent from burning too hot.





Material Specification:

Housing Molding shaped stainless steel housing
Gasket EPDM gasket
Glass Step tempered glass. T=8mm
Loading capacity Exert force area of ø10 = 210kgs, ø30= 550gs , ø60 =800kgs
Lens All-in-one optical lens, efficiency≥85%
Cable gland IP-68 PG-11 copper and nickel coated
LED Emitter type power LED
PCB

Excellent heat conductivity aluminum,

coefficient of heat conductivity≥2.0w/mk

Driver

Constant current output,

Single color LED=2-circuit output,

RGB 3in1 LED=6-circuit output

Application environment:

Temperature of water between -20℃~40℃,

less than 1 meter depth.

Power cable

H07RN-F 2X1.0mm² L=3m (for Single color),

H07RN-F 4X1.0mm² L=3m (for RGB)

Mounting sleeve PVC Mounting Sleeve included









Technical Information:

Item No. Light Source Lens

Beam

Angle

Input

Voltage

(V)

Typical

Operating

Current(mA)

Typical

Power

(W)

Typical

Luminance

(lm)

IK
Rate
C4Z1216 12*2W Osram C8 45°|35° 24VDC 930 22.5

Cool white=950
Warm white=807

08
C4Z1218

12*3W 3-in-1

RGB Full Color

C8 45°|35° 24VDC

R=250
G=440
B=460

R=6
G=10.6
B=11
R=200
G=310
B=90
08



Note:

1. Color options: Warm White, Neutral White, Cool White, Red, Green, Blue,RGB and etc;

2. Specification and availability are subjected to change without notice.

3. For more detail specification in PDF, please contact us separately







Dimensional Drawing(mm):

C4D1216 C4D1218 12pcs * 2W or 3W Asymmetrical Underwater Pool Lights Stainless Steel , LED Pool Lamp Corrosion Resistant 0







C4D1216 C4D1218 12pcs * 2W or 3W Asymmetrical Underwater Pool Lights Stainless Steel , LED Pool Lamp Corrosion Resistant 1

12V or 24V 3W RGB Small Size LED Underwater Pool Lights Asymmetrical Light Distribution





C4D1216 C4D1218 12pcs * 2W or 3W Asymmetrical Underwater Pool Lights Stainless Steel , LED Pool Lamp Corrosion Resistant 3
