Model No.︰cl-wlb-b4
Brand Name︰comlite
Country of Origin︰China
Unit Price︰-
Minimum Order︰-
Feature :
1.High power LED fountain light install in water for decoration or illumination. It is widely used for fountain pool, theme park, etc
2.Single color (pure white, warm white, red, green, blue, yellow)RGB and RGB3in1 color available
3.Stainless steel housing.IP68,built-in constant current driver, input voltage 24V DC, low consumption and safe for humaneasy and easy to install
|
Housing:
|
molding shaped 316# stainless steel housing
|
|
Glass:
|
clear tempered glass T=10mm
|
|
Lens:
|
optical lens, efficiency ≥85%
|
|
Cable gland:
|
IP-68 PG-11 copper and nickel coated
|
|
PCB:
|
excellent heat conductivity aluminum, coefficient of heat Conductivity ≥2.0w/mk
|
|
LED:
|
9pcs High power LEDs
|
|
Driver:
|
constant current output
Single color LED=2-circuit output
RGB 3in1 LED=6-circuit output
|
|
Application environment:
|
temperature of water between-20°C～40°C, less than 1 meter depth
|
|
Power cable:
|
H05RN-F 2X1.0m㎡ L=3m (for Single color)
H05RN-F 4X1.0 m㎡ L=3m (for RGB color)
|
|
Part No.
|
Light Source
|
Lens Beam Angle(°)
|
Input Voltage(V)
|
Operating Current(mA)
|
Consumption(W)
|
Luminance
(lm) |
|
|
B4TA0916
|
9X2W
|
25
|
24VDC
|
882
|
21
|
Cool white=820
Warm white=750 |
|
|
B4TA0918
|
9X2W
RGB 3in1 |
25
|
24VDC
|
R=284
|
R=6.8
|
R=218
|
|
|
G=460
|
G=11
|
G=461
|
|||||
|
B=451
|
B=10.8
|
B=95
|
|||||
|
B2TB0916
|
9X2W
|
25
|
24VDC
|
882
|
21
|
Cool white=820
Warm white=750 |
|
|
B2TB0918
|
9X2W
RGB 3in1 |
25
|
24VDC
|
R=284
|
R=6.8
|
R=218
|
|
|
G=460
|
G=11
|
G=461
|
|||||
|
B=451
|
B=10.8
|
B=95
|
Payment Terms︰ TT/Paypal
